Horing Lih AH-0621 Photoelectric Smoke Detector

Photoelectric Smoke Detector

Fire Alarm (FA) System

Characteristics

  • Contacts material is highly acid-resistant and rust-resistant.
  • Twin-color LED display enables viewer to easily identify the current status of detector.
  • Detector is made of high endurance, solid and colorfast Fire-proof plastic.
  • The standard detector is 2-wire or 3-wire. For 4-wire type just add one relay output module on 3-wire base. Simple and easy module placement enables wider application and flexible stock control.
  • Non-loosening screws on base terminal for easy installation.
  • Detector has passed strict EMC test, which greatly eliminates false alarms caused by interference from nearby sources.

Product PDF
Specifications
ModelAH-0621-2AH-0621-3AH-0621-4
Alarm ContactN/AN/A0.8A@30VDC

0.4A@125VAC

Voltage Range12 ~ 30VDC
Alarm Current @24V DC 470Ω50mA59mA45mA
Standby Current@24V DC 470Ω140μA25~75μA
Sensitivity SettingComply to UL 268
Ambient Temperature0°C ~+ 37.8°C
MaterialFire -proof plastic
Dimensions102mm(Dia.)x48mm(H)
Weight130g130g145g
ColorWhite
